Spectrum preview
Title
MIR DRIFT spectrum of MtBl chlorite at 860C
Database
Experiment type
laboratory measurement
Spectrum type
absorbance
Version
#1 (2017-09-08 14:13:21 UTC+0000)
Instrument parameters
Instrument
Nicolet6700
Spectral observation mode
spectrum
Valid spectral range(s)
650.0 - 4000.0 $cm^{-1}$
Observation geometry
hemispheric-hemispheric
Angle observation mode
N/A
Spatial observation mode
single spot
Sample preview
Name
Sptb chlorite mixed with diamond powder (15% chlorite) at 25°C
Origin
None
Texture
loose granular
Thickness
0.5 $\pm$ 0.01 $cm$
Temperature
860.0 $\pm$ 10.0 $^{\circ}C$
Fluid
References
Data reference
Lempart, Malgorzata (2015): MIR DRIFT spectrum of MtBl chlorite at 860C. Version 1. SSHADE/LSD (OSUG Data Center). Dataset/Spectral Data.
