- Instrument
- SHADOWS Spectro-Gonio bidirectional reflection Vis-NIR
- Spectral observation mode
- spectrum
- Valid spectral range(s)
- 400.0 - 660.0 $nm$ ; 680.0 - 1480.0 $nm$ ; 1500.0 - 2980.0 $nm$ ; 3000.0 - 4200.0 $nm$
- Observation geometry
- bidirectional : i=0.0° ; e=60.0° ; az=0.0° ; ph=60.0°
- Angle observation mode
- one variable angle
- Spatial observation mode
- single spot
- Name
- raw lunar soil 78221
- Texture
- loose granular
- Thickness
- 1.0 $\pm$ 0.1 $mm$
- Temperature
- 23.0 $\pm$ 2.0 $^{\circ}C$
References
- Data reference
- Beck, Pierre; Potin, Sandra (2018): Vis-NIR reflectance spectra (i=0°, e=30° and 60°) of 4 lunar soils (Appolo 15, 16, 17) under ambient conditions. SSHADE/GhoSST (OSUG Data Center). Dataset/Spectral Data. https://doi.org/10.26302/SSHADE/EXPERIMENT_LB_20180503_001
