Sample

Name: JSC Mars-1 (Original)

Owner of sample

Database

BYPASS

Experimentalists

Zuriñe Yoldi

Origin of sample

Date: 2016-11-18

Sample JSC Mars-1 (Original) in the sample holder during the measurement.

Sample JSC Mars-1 (Original) under an optical microscope.

Sample JSC Mars-1 (Original) under an Scanning Electron Microscope (from Brouet et al., 2016).

Physical characteristics

Thickness: 20.0 $\pm$ 1.0 $mm$
Diameter: 20.0 $mm$
Substrate material: aluminum sample holder covered with a black aluminum tape

Sample environment: Temperature

Temperature: 293.0 $\pm$ 2.0 $K$

Sample environment: Fluid

Type: ambient air
Fluid temperature: 293.0 $K$
Fluid pressure: 1.0 $bar$

Layers in sample

Number

1

Layers

Layer #1 , 20.0 $mm$

Sample processings
