Sample
Name
Ammonium sulfate (67 wt%) mixed with graphite powder at 296 K
Database
Experimentalists
Date
2018-09-28
Fragment of the mixture of graphite and ammonium sulfate (67 wt%) measured by Scanning Electron Microscopy on 05/10/2018.
Zoom on a fragment of the mixture of graphite and ammonium sulfate (67 wt%) measured by Scanning Electron Microscopy on 05/10/2018. The layers of graphite can be observed, but the exact location of the ammonium salt is unclear.
Physical characteristics
Thickness
1.0 $\pm$ 0.1 $mm$
Diameter
10.0 $mm$
Substrate material
aluminum sample holder
Substrate comments
The sample holder is 10 mm in diameter and 1 mm deep
Temperature
296.0 $K$
Temperature max
296.0 $K$
Type
ambient air
Fluid temperature
296.0 $K$
Number
1
Layers
