- Database
- Experimentalists
- Date
- 2023-12-01
- Provider
- IPAG collection
- Local reference code
- erock-SPZ-987690_plM2-H8
- Thickness
- 1.0 $\pm$ 0.3 $mm$
- Surface roughness
- polished
- Substrate material
- epoxy resin
- Substrate comments
- finely polished pellet, D=25mm
- Comments
- quite homogeneous grain (1.8 x 2.4 mm) but with a few small Fe-poor inclusions and some fractures partly filled with a little Fe oxides. Included in a finely polished epoxy resin pellet (# M2)
- Temperature
- 295.0 $\pm$ 5.0 $^{\circ}C$
- Type
- ambient air
- Fluid temperature
- 295.0 $^{\circ}C$
- Fluid pressure
- 1.0 $bar$
- Number
- 1
- Layers
-
- Fe-Magnesite grain , 1.0 $mm$
