Spectrum preview
Title
Fe K edge XAS transmission of bulk LEOVILLE CV chondrite: raw spectrum
Database
Experiment type
laboratory measurement
Spectrum type
raw
Version
#1 (2020-01-10 16:12:04 UTC+0000)
Instrument parameters
Instrument
X-ray Absorption Spectroscopy measured in transmission mode
Spectral observation mode
spectrum
Valid spectral range(s)
7004.000158439858 - 7385.000167058589 $eV$
Observation geometry
direct :
Angle observation mode
fixed angles
Spatial observation mode
single spot
Sample preview
Name
Pellet of Leoville CV chondrite mixed with BN
Texture
compact poor grained
Thickness
1.0 $\pm$ 0.5 $mm$
Temperature
293.0 $\pm$ 2.0 $K$
Pressure
1.0 $atm$
References
Data reference
Garenne, Alexandre; Bonal, Lydie; Beck, Pierre; Proux, Olivier (2013): Fe K edge XAS transmission of bulk CV carbonaceous chondrites. SSHADE/GhoSST+FAME (OSUG Data Center). Dataset/Spectral Data. https://doi.org/10.26302/SSHADE/EXPERIMENT_LB_20191211_005
Publications
